Voltage Per Unit 12
Capacity 28Ah@20hr-rate to 1.75V per cell @25°C
Weight Approx. 8.10 Kg
Max. Discharge Current 260 A (5 sec)
Internal Resistance Approx. 10 mΩ
Operating Temperature Range Discharge: -20°C~60°C
Normal Operating Temperature Range 25°C±5°C
Float charging Voltage 13.7 to 13.9 VDC/unit Average at 25°C
Recommended Maximum 7.8 A Charging Current Limit
Equalization and Cycle Service 14.6 to 14.8 VDC/unit Average at 25°C
Self Discharge EnerZell Valve Regulated Lead Acid (VRLA) batteries
can be stored for more than 6 months at 25°C.
Self-discharge ratio less than 3% per month at
25°C. Please charge batteries before using.
Terminal Faston F3/F13
Container Material A.B.S. (UL94-HB), Flammability resistance of UL94-V2
can be available upon request.
